EDM Brass Wire

Brass Wire

Diamond guide used, to ensure the accuracy of wire ø as high as ±0.001 mm

Superior straightness free from twisting and curl, which is optimum for automatic wire threading

We provide high quality wire which has a smooth surface finish without scratches, stains, and cracking.

EDM wire electrode increase the efficiency of operating. Drawn and annealed specially and guarantees a constant tensile strength.

Code	Wire Ø mm	weigth (Kg)	Packing
HSD-10-P3	0.10	3.0	6
HSD-15-P3	0.15	3.0	6
HSD-20-P5	0.20	5.0	4
HSD-25-P5	0.25	5.0	4
HSD-30-P5	0.30	5.0	4
HSD-20-P15	0.20	20.0	1
HSD-25-P15	0.25	20.0	1
HSD-30-P15	0.30	20.0	1

Wire Ø Tolerance	Compo.	Tensile Strength (N/mm2)	Hradness
-0.002 mm	Cu62Zn38	1000~1050	Hard Type

Wire Diameter	Breaking Load (KG)	Elongation	Conductivity
Ø0.10 mm	0.80~0.90	2%	22%
Ø0.15 mm	1.90~1.21	2%	22%
Ø0.20 mm	3.40~3.60	2%	22%
Ø0.25 mm	5.30~5.60	2%	22%
Ø0.30 mm	7.60~8.00	2%	22%
